COOL-LITE® XTREME

COOL-LITE® XTREME – Triple-Silver Coated Thermal Glass

The Saint-Gobain Glass COOL-LITE® XTREME range of commercial glazing has been developed with triple-silver coating technology, providing exceptional solar control capabilities whilst maintaining sleek, neutral aesthetics.

Suitable for a range of applications across the commercial glazing sector, the COOL-LITE® XTREME thermal insulation glass range provides superior thermal control, protecting against harsh solar radiation to keep interiors cool and comfortable even in the most intense sunlight. Providing enhanced energy efficiency whilst reducing reliance on artificial cooling systems, the COOL-LITE® XTREME range helps to minimise energy consumption, leading to cost savings and environmental benefits.

Developed to provide a consistently comfortable indoor environment to help promote productivity, comfort and therefore well-being among occupants, the COOL-LITE® XTREME high-performance glass seamlessly blends into diverse architectural designs and demands.

The COOL-LITE® XTREME range is available in a range of coatings to suit different requirements and is applied to our PLANICLEAR® range of glass as standard. However, when used in combination with STADIP® SILENCE or the standard STADIP® range, it can also provide noise reduction alongside safety and security, respectively.

energy efficient

Energy efficient

enhanced security

Enhanced security

solar control

Solar control

enhanced safety

Enhanced safety

overheating

Reduced overheating

thermal insulation

Thermal insulation

All images are for illustration purposes only

COOL-LITE® XTREME Applications

The COOL-LITE® XTREME range offers exceptional performance for applications demanding toughened or heat-treated glass. Engineered to provide superior solar control and thermal insulation, this cutting-edge glazing solution is ideal for:

FACADES AND WINDOWS
Enhance the energy efficiency of your building’s envelope with COOL-LITE® XTREME. Its advanced coatings minimise solar heat gain, reducing cooling costs and creating a comfortable indoor environment.

ROOFS AND SKYLIGHTS
Harness natural daylight while mitigating excessive heat buildup. COOL-LITE® XTREME is the perfect choice for overhead glazing, ensuring a well-lit and thermally regulated interior space.

CONSERVATORIES AND GLAZED BAYS
Enjoy the beauty of expansive glass surfaces without compromising on thermal performance. COOL-LITE® XTREME benefits from exceptional insulating properties keep your conservatory or glazed bay at an optimal temperature year-round.With its innovative technology and versatile applications, the COOL-LITE® XTREME range offers a comprehensive solution for architects, builders, and homeowners seeking to combine aesthetic appeal with energy-efficient design.

COOL-LITE® PERFORMANCE
Sealed Unit Configuration (6-16-4) Visible Light Energy Factors Solar Factor U Value Normal Internal Emissivity (Single Outer Pane) Selectivity
Outer Pane (Coating on Face 2) Inner Pane Total Light Transmission % External Reflection % Direct Transmission % External Reflection % g-value Argon (90%) W/mK
COOL-LITE® XTREME 70/33 II PLANICLEAR® 70 11 31 36 0.33 1.0 0.01 2.12
COOL-LITE® XTREME 61/29 II PLANICLEAR® 61 11 27 32 0.29 1.0 0.01 2.1
COOL-LITE® XTREME 50/22 II PLANICLEAR® 47 16 19 35 0.21 1.0 0.01 2.24
COOL-LITE® All the above hold CE marked performance accreditation for the products in their annealed and tempered state.

COOL-LITE® PERFORMANCE
Sealed Unit Configuration (6-16-4) Visible Light Energy Factors Solar Factor U Value Normal Internal Emissivity (Single Outer Pane) Selectivity
Outer Pane (Coating on Face 2) Inner Pane Total Light Transmission % External Reflection % Direct Transmission % External Reflection % g-value Argon (90%) W/mK
COOL-LITE® SKN 183 II PLANICLEAR® 75 12 38 34 0.4 1.0 0.01 1.88
COOL-LITE® SKN 176 II PLANICLEAR® 70 13 35 32 0.37 1.0 0.01 1.89
COOL-LITE® SKN 175 II PLANICLEAR® 70 14 33 37 0.35 1.0 0.01 2.00
COOL-LITE® SKN 165 II PLANICLEAR® 61 16 32 34 0.34 1.0 0.01 1.79
COOL-LITE® SKN 154 II PLANICLEAR® 52 18 26 30 0.28 1.0 0.01 1.86
COOL-LITE® SKN 144 II PLANICLEAR® 42 20 20 31 0.23 1.1 0.03 1.83
All the above hold CE marked performance accreditation for the products in their annealed and tempered state.

Saint-Gobain Glass reserves the right to change product performance features without notice or obligation.
Contact your Saint-Gobain sales representative to check the availability of each product in your country.
